Black Magic

• 2 x 4K SDI Input
• 1 x HDMI Type A and 1 x SDI Output
• Supports SD, HD, UHD 4K & DCI 4K Signals
• Automatic Input Signal Detection
• 24-Bit, 48 kHz Audio
• Analog & AES-EBU Digital Audio Outputs
• De-Embeds Audio from SDI
• Settings via Mini Switches or Software
• USB 2.0 Port for Firmware Updates
• 12V Universal Power Supply Included

• Mini Converter Series
• Six Output
• Tri-Sync or Black Burst

• Supports SD/HD/3G/6G-SDI
• Auto Format Sensing & Selection
• 1 x Loop-Through SDI I/O per Monitor
• Select Video, Waveform, Vectorscope
• RGB Parade, YUV Parade, Histogram
• Audio Phase & Levels
• Software Control via Ethernet
• Industry Compatible Tally System
• 3 Rack Unit Size for Mounting
• Auto Orientation Sensing & Image Flip

• 3G/HD/SD-SDI Inputs, Both with Loop-Out
• Integrated Tally for Live Broadcast
• Ethernet Input for Adjustments
• Upgradeable Firmware via USB
• 2K, 1080i/p, 720p & 50/60 Hz SD Support
• 10-Bit Color & 4:2:2 / 4:4:4 Sampling
• 800 x 480 Resolution

• Advanced High-Data Rate Embedder
• Embed Audio into up to 4K SDI Signals
• Embed via XLR, AES/EBU, RCA, or S/PDIF
• 12G-SDI Input and Output
• Supports up to Full 4K DCI 4096x2160p
• XLR Connections Switchable to AES/EBU
• Ethernet Port for Remote Control or PoE
• Supports Optional LCD Smart Front Panel
• Intelligent Thermal Heat Dissipation
• 3 Units 1U Rack-Mountable in 19″ Rack

• Convert an HDMI Signal to 12G-SDI
• Convert HDMI to Optical Fiber (Optional)
• Up to DCI 4K/60p Support on Input/Output
• XLR Inputs Switchable to AES/EBU
• Ethernet Port for Remote Control or PoE
• Built-In 90-240V Power Supply
• Rack-Mount, Duct or Desktop Installation
• Install up to 3 Units in Single 19″ Rack
• Supports Optional LCD Smart Front Panel
• Intelligent Thermal Heat Dissipation

• Convert a 12G-SDI Signal to HDMI
• Convert Optical Fiber to HDMI (Optional)
• Up to DCI 4K/60p Support on Input/Output
• XLR Outputs Switchable to AES/EBU
• Ethernet Port for Remote Control or PoE
• Built-In 90-240V Power Supply
• Rack-Mount, Duct or Desktop Installation
• Install up to 3 Units in Single 19″ Rack
• Supports Optional LCD Smart Front Panel
• Intelligent Thermal Heat Dissipation

• Quad-Link 12G-SDI Input
• 2 Single-Link 12G-SDI Outputs
• Supports SD, HD, UHD 4K & DCI 4K Signals
• Automatic Input Signal Detection
• 24-bit, 48 kHz Audio
• Control via DIP Switches or Software
• USB 2.0 Port for Firmware Updates
• Requires IEC C14 Power Cable

• Advanced High-Data Rate De-Embedder
• De-Embed Audio from up to 4K SDI Signals
• Output via XLR, AES/EBU, RCA, or S/PDIF
• 12G-SDI Input and Output
• Supports up to Full 4K DCI 4096x2160p
• XLR Connections Switchable to AES/EBU
• Ethernet Port for Remote Control or PoE
• Supports Optional LCD Smart Front Panel
• Intelligent Thermal Heat Dissipation
• 3 Units 1U Rack-Mountable in 19″ Rack

• Supports DCI 8K, 8K, DCI 4K, UHD, 2K, HD
• Accepts Third-Party Calibration Probes
• 12G-SDI I/O / DisplayPort/USB-C D.P. Out
• 2 x Selectable, On-Screen Scopes
• Auto-Convert 2SI and Square Division
• Supports HDR Workflows
• Supports 33-Point 3D LUTs
• Front-Panel Interface, Audio Meters
• Rack-Mountable with Separate Kit

• Attaches to Teranex Mini & Web Presenter
• Replaces Standard Front Panel
• 2.2″ Color LCD, Spin Dial & Push Buttons
• Adjust Settings, Browse Menus
• Monitor Conversions & Audio Levels
• Verify Timecode & Video Standard

UltraStudio 4K Extreme 3 is the world’s most advanced capture and playback solution for PCI Express and Thunderbolt computers! It features incredibly fast 40Gb/s Thunderbolt 3, advanced 12G‑SDI and HDMI 2.0 connections for working at up to 60 frames per second with deep color, 12‑bit RGB, support for HDR workflows via HDMI 2.0a and extremely large 4K frame sizes. Featuring the widest range of analog and digital connections, UltraStudio 4K Extreme 3 is compatible with virtually any camera, deck, router or display. There’s even an extremely powerful hardware encoder built-in that supports realtime H.265 encoding!
